• STRUCTURE
Land survey - Soil test investigation - Earth quake resistant – Fe 550 TMT bar – wire cut Red
brick walls – OPC 53 for RCC and PPC 43 grade cement for other works - ULTRA TEC RMC will
be used in foundation & roof slab concrete works - Gypsum board false ceiling for Living/
dining and all Bed rooms. Basement height 2’.6”.
• FLOORING
Vitrified tiles from Kajaria/ Somany/ Equivalent, 6’ x 4’ for living and dining (Rs.120 per sft)
and 4’ X 2’ for bedrooms and kitchen (Rs.80 per sft). Exterior vitrified tiles for car park over
M 5 Grade RMC and interlocking Paver blocks for setback areas. Heat Resistant Tiles for the
Terrace of make Insulla/ Equivalent.
• TOILET AND UTILITY
Kajaria/Somany/Equivalent tiles 24”x12” Rs.65 per sft for Toilets, Kitchen, For Utility walls
24" x 12" - Rs 60 per sft and Anti skid/ matt 12”x12”tile Rs.60 for floor. Epoxy grouting for
tiles, with waterproofing (Sunken areas) in Utility and Toilets. Toilet ceiling finished with
24" x 24" grid false ceiling. A stainless steel towel rod - 1 No & 12" glass corner shelf will be
provided.
• SANITARY AND PLUMBING
CPVC for concealed line, and UPVC open pipeline for fresh water and PVC pipeline for sanitary
and Kitchen of Finolex/Ashirwad/Astral/Equivalent.
Wall mounted closet with concealed tank of Jaquar/Equivalent.
Taps and fittings will be CP of make Jaquar/Equivalent
• KITCHEN
Black galaxy granite for counter and Stainless steel sink with drain board of Niralli/Equivalent.
Provision for RO Unit & Dish washer. Shelves with 4 Nos of granite will be provided.
• ELECTRICAL
Chemical earthing – M.S. fabricated powder coated Panel Board, Independent DB with circuit
Breakers and RCCB. FRLS cables from ORBIT/Q-Flex/Equivalent &- Legrand/Equivalent
Modular switches, with Adequate 5 amps and 15 amps points
• JOINERIES
DOORS
3’ 6"x 8’ First quality African teak, with 5”x3” for frame and 1 ½” thick planks for Main door
with Floral carving , 3’x 8' First quality African teak frames and waterproof flush doors with
both sides 1mm thick laminate & CNC grooves for Bedrooms,, 2’.6” x 8' First quality African
teak frames and waterproof flush doors for toilets. All Hardware will be Stainless steel
• PAINTING
Internal walls will be two coats of cement based Putty, and two coats of premium Emulsion
with one coat of Primer of Asian/Equivalent. External surface will be Texture, Exterior primer
and two coats of Apex grade emulsion of Asian/Equivalent. Main door will be polished with
melamine spray.
• WINDOWS
UPVC open able windows with 5 mm thick plain glass for Living, Dining & bedrooms, UPVC
sliding window with 4m thick plain glass for kitchen, 12mm x 12mm Bright bar gills embedded
in to the wall. French door will be sliding with toughened glass of size 8' x 7'. 2’ x 2’ UPVC
fixed louver for ventilator with exhaust fan provision in toilets.
• OHT AND UG SUMP
4 ½” Outer brick wall and RCC inner wall with water proofing of 5000 liters for metro water
and 3000 liters for Bore water at OHT, and 15000 liters RCC wall with water proofing for UG
sump. Automatic water level controller will be provided for metro water pump
6” dia Bore well as per the water level in the area will be provided
• LIFT
8 Passenger Auto door lift (EMPEROR) up to terrace floor with 3 years AMC and License will
be procured.
• GENERATER
Generator (KIRLOSKAR) will be provided to support Lift, Common lights, Pumps and Only
Light & fan points and one 56 Amps point in the bed room & 16 Amps point for Fridge in
kitchen to the inside the flat.
• PEST CONTROL
Anti termite pest control treatment will be done at footing, around plinth beam, Brickwork
and paving block laying stages.
• Common Ammonites
• 8 Unit CCTV
• Access control system with glass
• Piped gas with cylinder storage room
• SS Staircase railing
• Balcony hand rail with SS & toughened glass
• Rain water harvest
• Separate Servant Room & Toilet in GF
• Landscape
• Seating arrangement at terrace and car park
• Party Table & wash basin provision at terrace
• Granite for steps and Landing in Common staircase
• Compound wall 5' ht with necessary gate provision at front side
• Name board
• Pressure booster pump
• granite putty in window bottom jams
• Electrical vehicle charger in car park area
• Elegant elevation features
• Elegant Lobby space in GF.
