1.STRUCTURE
R.C.C framed structure with Red Bricks only for External and internal walls
(Solid Blocks will be used for compound wall and other ancillary works), walls plastered and
finished with Two Coats of Cement based Putty, with one coat of primer and two coats of
Asian Premium Emulsion/Equivalent. Ceiling surfaces inside the apartments will be given one
coat of cement paint on the RCC surface and 12mm gypsum board false ceiling (in Living,
Dining, Bedrooms and Toilets) with galvanized iron section supports. Joints will be taped with
touchup putty and finished with one coat of primer and two coats of White colour Premium
Emulsion. Basement height will be 3’6” from road level.
2.JOINERY
a. Main door: First Quality African Teak both frame and shutters (Panel door) Polished both
sides with melamine spray.
b. Other doors: will be deep-moulded compressed wood fibre raised panel doors, strengthened
with pre-selected kiln dried rails and stiles, with a grain effect etched in the panel with first
quality teak frames, painted on both sides. All door frames will be country wood frames with
painting. Toilet doors will be prepainted ABS doors.
c. Windows: All windows will be UPVC windows, with 5mm glazed shutters and Bright Bar
grills embedded in the wall.
d. Ventilator: Toilet ventilators will be with aluminium adjustable louvers with inbuilt provision
for exhaust fan.
3. FLOORING
Vitrified tile flooring 2 x 2 from Kajaria/Somany/Nitco/Equivalent plain colours @ Rs.60/Sft, for
Living/ Dining, all bedrooms, kitchen, balconies and passages with 4” high skirting.
4. KITCHEN
Polished Black galaxy granite slab over cooking platform, NIRALI/ equivalent
Stainless steel sink with drain board and plain glazed tiles (10 x 16) upto 2’ height above the
platform.
5.TOILETS
Plain ceramic tile flooring, ceramic printed/ plain tile dado upto 7’ feet height from
floor, concealed plumbing arrangements.
6. SANITARYWARES & FIXTURES: PARRYWARE/ KOHLER equivalent wall mounted model
White closets with exposed tank provided in all bathrooms. Half turn foam flow taps and fittings
KOHLER or Equivalent for all toilets. Each toilet shall be provided with one water closet, one
wash basin, one wall mixer, shower rose, one health faucet, pillar cock & angle valve for wash
basin.
7.ELECTRICAL
Three phase electric supply connection with a separate Manual Three phase
changeover switches inside each flat and wiring will be of copper fire retardant cables
concealed in PVC conduits. MINIATURE CIRCUIT BREAKERS & RCCB (Residual Current
Circuit Breaker) will be provided and switches will be Modular Type mounted on metal boxes
from LEGRAND/ EQUIVALENT. Provision for A/C in Living room and in all bedrooms.
8. CHEMICAL EARTHING done for the building by digging 3m deep bores inserted with hot
dipped galvanized dual pipes, filled with high conductive and corrosion resistant crystalline
mixture and backfill compound around the electrodes.
9. WATER SUPPLY Corporation and borewell water supply in the kitchen, service and
bathrooms. New Borewell upto 300 feet depth will be provided.
10. LIFT ; A SIX Passenger AUTO DOORLIFT will be provided from EMPEROR/ CLAE/
Equivalent.
11. GENERATOR
Standby Generator with alternator, sound proof enclosure, control panel, change over panel
and earthing etc., will be provided to support the lift, common area lights, motors, and only
lights & fan points inside the flat
Special weather proofing treatment will be done to the mother terrace to reduce the heat
on the top floor.
12. ACCESS CONTROL with video door phone will be provided.
13. WATER TANK ;
Water tank will be done with 4 ½” brick work outside and 4 ½” thick RCC walls inside
with adequate water proofing and bifurication for metro water and bore water proofing
will be polymer based coating
14. UPVC Valve for interconnecting both the tanks will be provided.
Automatic Water level controller for overhead tank will be provided for metro water
pump and will be connected to the generator.
