1.STRUCTURE:
• Earth quack resistant – Fe 550 TMT bar – Clay bricks/Fly ash Brick walls – OPC 53 for RCC and PPC 43 grade cement for other works
• Gypsum board false ceiling for Living dining and all Bed rooms. Basement height 3'- 0”.
2. FLOORING:
• Vitrified tiles from Kajaria/Somany/Equivalent, Living Dinning 4' X 2' (Rs.100) Bedrooms, Kitchen and Balconies 2'x2' (Rs.50).
• Exterior vitrified tiles for car park and interlocking Paver blocks for setback areas. Heat resistant tiles for terrace of Insulla/equivalent.
3. TOILET AND UTILITY:
• Kajaria/Somany/Equivalent tiles 24”x12”/18”x12” for Toilets, Kitchen, Utility walls (Rs.50) and 12”x12” for floor( Rs.40).
• Epoxy grouting for tiles, with waterproofing (Sunken areas) in Utility and Toilets.
4. SANITARY AND PLUMBING:
• CPVC for concealed line, and UPVC open pipeline for fresh water and PVC pipeline for sanitary and Kitchen of Finolex/Equivalent.
• Wall mounted closet and Concealed tank of Jaquar/Toto/Equivalent.
• Taps and fittings will be CP Jaquar/equivalent.
5. KITCHEN:
Black galaxy granite for counter and 36”X20” SS sink with drain board of Nirali/Equivalent.
6. ELECTRICAL: Chemical Earthing – M.S. fabricated powder coated Panel Board, Independent DB with circuit Breakers and RCCB. FRLS cables of Orbit/RR/Q-Flex/Powerflex/Equivalent, Legrand/ Equivalent Modular switches, with Adequate 5 amps and 15 amps points. Exhaust fan for all toilets.
7. JOINERIES - DOORS
• 4'- 0"x 8' First quality African teak, with 5”x3” for frame and 1 ½” thick planks for Main door
• 3' x 8' First quality African teak frames and Skin mould doors for Bedrooms.
• 2' 6"x 7' First quality African teak frames and ABS doors for toilets. All hardware will be SS.
8. PAINTING:
• Internal walls will be two coats of cement based Putty, and two coats of premium Emulsion with one coat of Primer of Asian/Equivalent.
• External surface will be Texture, Exterior primer and two coats of Apex grade emulsion of Asian/Equivalent.
9. WINDOWS:
• UPVC sliding for kitchen and Open able for other windows with 5 mm plain glass and 12 mm Bright bar grills embedded in wall.
• French door will be sliding with toughened glass.
• UPVC Ventilators of size 2' x 2' with adjustable louver and exhaust fan will be provided for all toilets.
10. OHT AND UG SUMP:
• 4 ½” Outer brick wall and RCC inner wall with water proofing for OHT, and 18,000 liters RCC sump with water proofing for UG sump.
• Bore well up to the depth of water source will be provided.
• Auto water level controller for Metro water pump & connected to the generator power.
11. LIFT: 6 Passenger Auto door MS lift with License will be provided by Emperor lift /Equivalent.
12. GENERATOR: Generator will be provided to support Lift, Common lights, Pumps and Light and fan points, kitchen appliances, water heater and AC's inside the flat.
13. PEST CONTROL: Anti termite pest control treatment will be done at footing, around plinth beam, Brickwork and paving block laying stages.
14. COMMON AMENITIES:
• Access control
• Piped gas
• CCTV
• SS Staircase railing Seating arrangements in car park & terrace
• Party table with a wash basin at Terrace
• Rain water harvesting
•Separate servant room & toilet
• Granite for steps and landing in common staircase
• Landscaping
• Elegant elevation features
• Fire extinguisher
• EV charger.
